CP82
CHART PROJECTOR (Halogen lamp)
CP82 Auto Projector( Halogen lamp) can provide 30 types of clear icons with different functions, and can program icon groups per specific needs. It can produce more precise measurement results in shorter time by remote controller and fast toggling icon, applying red/green & polarized icon test sheet, binocular eyesight and binocular balance.
Easy installation and maitainence
It is quite easy to replace light bulks, and unnecessary to adjust its focus and position.
Customer Programmable
Icons can be displayed in predefined sequence by programming.
Display Single Icon
Display single icon by multi-function mask plate.
Tilted Placement
Perfect image position can be obtained by adjusting the horizontal axis of projector.
Specification: |
Projection distance: |
1.5m ~ 6m |
Projection magnification: |
30 x (at 5m) |
Projection size: |
330mm(W) x270mm(H) (at 5m) |
Chart : |
30 different pattern |
Speed of chart conversion: |
One chart per 0.03s |
Mask: |
1 open, 5 horizontal lines,8 vertical lines, 21 single letters, 1 red/green |
Speed of mask conversion: |
One mask per 0.03s |
Program: |
2 sets programs, each program contains up to 30 steps |
Light source: |
12V,50W Halogen Lamp |
Auto-off function: |
After 10 minutes idle time. |
Power source: |
AC 220V ,50Hz or 110V, 60Hz |
Power consumption: |
80W |
Accessories: |
Remote control, Polarized metal screen, halogen lamp, polarized glasses, fuses(2), batteries(2) |
|
|
